HW2TA2A Veris Wall Humidity Sensor
$ 99.05
SPECIFICATIONS Color : Matte White Display Resolution : 240 x 300 px Display Size : 2.4 in (61 mm) Display Type : LCD, Color, Backlit, Capacititve Touchscreen Electrical Wiring Size : Screw terminals, 18-24 AWG Enclosure Material : High impact ABS plastic Humidity Measurement Accuracy : ±2% from 10 to 80% RH @ 25°C (77 °F) Humidity Measurement Range : 0 to 100% RH Humidity Measurement Resolution : 0.1% RH Humidity Sensor Type : Thin-film capacitive, replaceable IP Protection : IP20 Input Specifications : Class 2; 20 to 30 Vdc, 24 Vac, 50 to 60 Hz Measurement Type : RH / Temperature Operating Humidity : 0 to 95% RH non-condensing Operating Temperature : 0 to 50 °C (32 to 122 °F) Output Specifications : Selectable 4 to 20 mA, 0 to 5 V, 0 to 10 V Outputs : Analog Override : Yes Setpoint Range : Temperature: 0 to 50 °C (32 to 122 °F) / 10 to 35 °C (50 to 95 °F), selectable Humidity: 0 to 100% RH. Fan Speed: Off, Low, Med., High. Setpoint Specifications : 0-10Vdc. Temperature, humidity or fan speed (one setpoint type is selectable via dip switch) Setpoint : Yes Standards EMC : EN61000 Series – industrial immunity Temperature Measurement Accuracy : ±0.2 °C (±0.4 °F) typical Temperature Measurement Range : 0 to 50 °C (32 to 122 °F) Temperature Measurement Resolution : 0.1 °C (0.1 °F) Temperature Sensor Type : Solid state, integrated circuit Warranty : 5 Years FEATURES The Veris HW2 Series of humidity sensors for living space is a flexible multi-sensor platform for use with various brands of BAS controllers designed to accept 4 to 20mA, 0 to 5Vdc, 0 to 10Vdc, and various thermistor outputs. HW2 Series sensors feature no-logo on the faceplate and are available with three user interface options: touchscreen, LCD with three buttons and blank. Humidity and temperature sensors are included with all HW2 Series sensors DOCUMENTS Datasheet Installation guide
